CYCOLOY™ FR Resin CY6310

CYCOLOY™ FR Resin CY6310

Manufacturer: SABIC
Produced At: Import/ China
Product Category: Polycarbonate + ABS
Product No: CYCOLOY FR Resin CY6310
Product Quantity: 25KG / BAG
Product Features: Bromine Free，Chlorine Free，Flame Retardant，Hydrolytically Stable

CYCOLOY™ FR Resin CY6310

Polycarbonate + ABS
Product Description:
CYCOLOY CY6310 Polycarbonate/Acrylonitrile Butadiene Styrene (PC/ABS) resin is a hydrolytically stable, impact modified grade that can be injection molded. This non-chlorinated, non-brominated flame retardant PC/ABS has a UL V0 & 5VA/B flame rating. CYCOLOY CY6310 resin is an excellent candidate for a wide variety of large size of applications including appliances, lighting, electrical and enclosures.
Additive

  • Flame Retardant

Features
  • Bromine Free，Chlorine Free，Flame Retardant，Hydrolytically Stable
Uses
  • Appliances，Construction Applications，Electrical/Electronic Applications，Lighting Applications
Processing Method

  • Injection Molding

Also Available In
  • Asia PacificEurope
Physical
Nominal Value
Unit
Test Method
Density / Specific Gravity



--
1.17

ASTM D792
--
1.17
g/cm³
ISO 1183
Melt Mass-Flow Rate (MFR)


ASTM D1238
250°C/2.16 kg
16
g/10 min

260°C/2.16 kg
20
g/10 min

Melt Volume-Flow Rate (MVR) (260°C/2.16 kg)
1.16
in³/10min
ISO 1133
Molding Shrinkage - Flow (0.126 in)
4.0E-3 to 6.0E-3
in/in
Internal Method
Water Absorption


ISO 62
Saturation, 73°F
0.60
%

Equilibrium, 73°F, 50% RH
0.20
%

Mechanical
Nominal Value
Unit
Test Method
Tensile Modulus



-- 2
392000
psi
ASTM D638
--
392000
psi
ISO 527-2/1
Tensile Strength



Yield 3
9140
psi
ASTM D638
Yield
9140
psi
ISO 527-2/50
Break 3
7250
psi
ASTM D638
Break
7400
psi
ISO 527-2/50
Tensile Elongation



Yield 3
4.2
%
ASTM D638
Yield
4.4
%
ISO 527-2/50
Break 3
> 50
%
ASTM D638
Break
> 50
%
ISO 527-2/50
Flexural Modulus



1.97 in Span 4
392000
psi
ASTM D790
-- 5
384000
psi
ISO 178
Flexural Stress



-- 5, 6
13200
psi
ISO 178
Yield, 1.97 in Span 4
14600
psi
ASTM D790
Impact
Nominal Value
Unit
Test Method
Charpy Notched Impact Strength 7


ISO 179/1eA
-22°F
6.7
ft·lb/in²

73°F
26
ft·lb/in²

Charpy Unnotched Impact Strength 7 (73°F)
No Break

ISO 179/1eU
Notched Izod Impact



-22°F
2.2
ft·lb/in
ASTM D256
73°F
11
ft·lb/in
ASTM D256
-22°F 8
6.2
ft·lb/in²
ISO 180/1A
73°F 8
24
ft·lb/in²
ISO 180/1A
Unnotched Izod Impact Strength 8 (73°F)
No Break

ISO 180/1U
Instrumented Dart Impact



73°F, Total Energy
575
in·lb
ASTM D3763
--
77.4
ft·lb
ISO 6603-2
Thermal
Nominal Value
Unit
Test Method
Deflection Temperature Under Load



66 psi, Unannealed, 0.126 in
212
°F
ASTM D648
264 psi, Unannealed, 0.126 in
190
°F
ASTM D648
264 psi, Unannealed, 0.157 in, 2.52 in Span 9
194
°F
ISO 75-2/Af
Vicat Softening Temperature



--
228
°F
ASTM D1525 10, ISO 306/B50 10
--
232
°F
ISO 306/B120
Ball Pressure Test


IEC 60695-10-2
163 to 171°F
Pass


203°F 11
Pass


CLTE



Flow : -40 to 104°F
3.8E-5
in/in/°F
ASTM E831, ISO 11359-2
Transverse : -40 to 104°F
3.9E-5
in/in/°F
ASTM E831
Transverse : -40°F
3.9E-5
in/in/°F
ISO 11359-2
RTI Elec
185
°F
UL 746
RTI Imp
185
°F
UL 746
RTI Str
185
°F
UL 746
Electrical
Nominal Value
Unit
Test Method
Surface Resistivity
> 1.0E+15
ohms
IEC 60093
Volume Resistivity
> 1.0E+15
ohms·cm
IEC 60093
Comparative Tracking Index
575
V
IEC 60112
High Amp Arc Ignition (HAI) 12
PLC 0

UL 746
Hot-wire Ignition (HWI)
PLC 3

UL 746
Flammability
Nominal Value
Unit
Test Method
Flame Rating


UL 94
0.030 in
V-2


0.030 in, Testing by SABIC
V-2


0.06 in
V-0


0.06 in, Testing by SABIC
V-0


0.09 in
5VB


0.09 in, Testing by SABIC
5VB


0.11 in
5VA


0.11 in, Testing by SABIC
5VA


Glow Wire Flammability Index (0.12 in)
1760
°F
IEC 60695-2-12
Oxygen Index
30
%
ISO 4589-2
Injection
Nominal Value
Unit

Drying Temperature
194 to 212
°F

Drying Time
2.0 to 4.0
hr

Suggested Max Moisture
0.020
%

Hopper Temperature
140 to 176
°F

Rear Temperature
410 to 464
°F

Middle Temperature
446 to 518
°F

Front Temperature
464 to 536
°F

Nozzle Temperature
446 to 518
°F

Processing (Melt) Temp
482 to 536
°F

Mold Temperature
140 to 194
°F
