ACRYLITE® Heatresist FT15
聚甲基丙烯酸甲酯-丙烯酸
When high heat resistance and lighting efficiency is desired ACRYLITE® Heatresist acrylic compounds provide the solution. They offer all the advantages of PMMA including weatherability and optics but provide another level of heat resistance. These copolymers are based on methyl methacrylate (MMA) with comonomer constituents. They are ideal for technical parts subjected to high thermal stress.
ACRYLITE® Heatresist molding and extrusion compounds are offered in two grades. ACRYLITE® hw55 and ACRYLITE® FT15 offer the following benefits:
ACRYLITE® Heatresist FT15 offers very high heat resistant characteristics compared to most other grades of ACRYLITE® polymer. Higher melt volume rates than ACRYLITE® Heatresist hw55.
特性 | |
用途 | - Lighting Applications、船舶应用、镜头、汽车领域的应用、医疗/护理用品
|
机构评级 | |
外观 | |
形式 | |
加工方法 | |
密度 | 1.19 | g/cm³ | ISO 1183 |
熔融体积流量（MVR） (230°C/3.8 kg) | 0.275 | in³/10min | ISO 1133 |
收缩率 | 0.20 到 0.50 | % | ISO 294-4 |
吸水率 |
|
| ISO 62 |
饱和, 73°F | 2.0 | % |
|
平衡, 73°F, 50% RH | 0.46 | % |
|
拉伸模量 | 508000 | psi | ISO 527-2/1 |
拉伸应力 (断裂) | 7250 | psi | ISO 527-2/5 |
拉伸应变 (断裂) | 3.1 | % | ISO 527-2/5 |
简支梁无缺口冲击强度 | 8.6 | ft·lb/in² | ISO 179/1eU |
热变形温度 |
|
|
|
66 psi, 未退火 | 225 | °F | ISO 75-2/B |
264 psi, 未退火 | 221 | °F | ISO 75-2/A |
玻璃转化温度 | 250 | °F | IEC 10006 |
维卡软化温度 | 239 | °F | ISO 306/B50 |
线形热膨胀系数 - 流动 (32 到 122°F) | 3.7E-5 | in/in/°F | ISO 11359-2 |
UL 阻燃等级 (0.06 in) | HB |
| IEC 707 |
Fire Rating | B2 |
| DIN 4102 |
折射率 | 1.502 |
| ISO 489 |
透射率 | 91.0 | % | ISO 13468-2 |
